Application

To coat solvent free silicon through three roll / five roll / six roll coating system unit with a camel back drying system

Paper From 40 gsm - 150 gsm
Pet All suitable dry lam range.
Speed 400 MPM

Coating Method

Silicon coating - Three roll/Five roll/six roll coating (specially designed) Pneumatic application for doctor blade and pressure roller, drying hood in coating units.

Drying tunnel is distributed in 5 heating zones having gas fired hot air based drying system.

Chilling roller outside top dryer are of 300 mm in dia with spiral circulation to remove the heat from surface before rewinding.

A gear box and differential gauge based micro gap adjustment facilities in between gravure roll and impression roll will be provided in the machine. 1919
