Application:-

Perfectly suitable to salvage any type of wrongly build up & defective printed, laminated reels with minimum change over time by single operator. Feature of Inkjet printing on film surface online also can be incorporated.

Technical Specification:-

Materials to be processed Aluminum Foil, Laminates
Maximum Outer Diameter 500 mm
Maximum Mechanical Speed 300 MPM

General Specification:-

  • Table top differential model to suit your specific need

  • All passing rollers are heavy duty and dynamically balanced

  • Air shaft on re-winder & un-winder for a quick change over

  • Heavy duty three roll assembly of rollers will travel horizontally with unwind shaft on linear motion bearing and imported hardened shaft ensure correction for any type of detect on material

  • Option of standard pneumo-hydraulic web-aligner or photocell sensor.

  • On line slitting arrangement.

  • Speed & total length meter indicator.

  • On line print defect stoppage provision

  • Machine will return in reverse direction to exact defect print.

  • Online Inkjet printing in-sync with speed, time & photocell mark.

  • Option to print in both direction (forward & reverse).

  • Also in continuous mode print defect can be flagged & in reverse operation machine will stop at defect flagged position.
